Flange

The flange is a part connected between the shaft and the shaft, which is used for the connection between the pipe ends; It is also useful in the flange on the import and export of the equipment for the connection between two devices, such as the reducer flange. Flange connection or flange joint refers to a detachable connection which is connected by flanges, gaskets and bolts as a group of combined sealing structures. There are holes in the flange and bolts make the two flanges tightly connected. The flange is sealed with a gasket.

Send Inquiry

Product Description

Flanges are divided into threaded connection (thread connection) flanges, welded flanges and clamp flanges. Flanges are used in pairs, wire flanges can be used for low pressure pipes, and welded flanges for more than four kilograms of pressure. Put a gasket between the two flanges and fasten them with bolts. Different pressure flange thickness is different, they use different bolts. Pumps and valves, when connected with pipelines, the local parts of these equipment are also made into corresponding flange shapes, also known as flange connections. All the connecting parts that are connected by bolts around two planes and are closed at the same time are generally called "flanges", such as the connection of ventilation pipes, and this type of part can be called "flanged parts". But this connection is only a part of the equipment, such as the connection of the flange and the pump, it is not good to call the pump "flange parts". Relatively small such as valves, etc., can be called "flange parts".

Product Parameter

DN	Pipe Dia	Connection Size				C	N	H	NPT
DN	A	D	K	L	n	C	N	H	NPT
10	17.2	75	50	11	4	12	25	2	3/8
15	21.3	80	55	11	4	12	30	20	1/2
20	26.9	90	65	11	4	14	40	24	3/4
25	33.7	100	75	11	4	14	50	24	1
32	42.4	120	90	14	4	16	60	26	1 1/4
40	48.3	130	100	14	4	16	70	26	1 1/2
50	60.3	140	110	14	4	16	80	28	2
65	76.1	160	130	14	4	16	100	32	2 1/2
80	88.9	190	150	18	4	18	110	34	3
100	114.3	210	170	18	4	18	130	40	4
125	139.7	240	200	18	8	18	160	44	5
150	168.3	265	225	18	8	20	185	44	6
